I/O Addressing Format in Omron PLC | Input and Output Addressing
Before going in to the addressing , first of all let us understand the numbers of input and output distribution.
The ratio of Input to Output in Omron PLC is always 3/2 i.e if we have a PLC of 40 I/O then there will be 24 inputs and 16 outputs.
Note :- Only in Compact PLC.
Input Addressing Format :- In Omron PLC there are 12 inputs in one slot so addressing start from 0.0 to 0.11 and then 1.0 to 1.11 and so on.
So if there are 18 inputs then address of input will be from 0.0 to 0.11 and 1.0 to 1.7.
Output Addressing Format :- In Omron PLC there are 8 outputs in one slot and the addressing is as follows :-
CPM1A/CPM1A PLC :- 10.0 to 10.7 , 11.0 to 11.7 and so on .
CP1E/CP1H PLC :- 100.0 to 100.7 , 101.0 to 101.7 and so on.
Other Memory Areas :-
Work Bits :- As we all know that every PLC have some internal bits to be used in program these
are known as memory or work bits. In Omron PLC these are called WORK bits and denoted by W.
Addressing Format :- w0.0 to w512.0
Note :- There are 16 bits in one words , so w0.0 to w0.15 and then w1.0 to w1.15
Also here one important point to see is that these are used as Bits but if you want to use them as WORDS that is also possible.
DATA MEMORY WORDS :- The data memory words in PLC are used to store the integer value or float value.
In OMRON PLC these are denoted by D and addressing Format is D0 to D322767.
HOLDING REGISTER :- In OMRON PLC the Holding registers are there ,
it is similar to Data Words except it retains its state even after power failure and also we can use it as Bits or Word.
Addressing Format :- H0 to H1535 ( is using as words)
Addressing Format :- H0.0 to H1535.15
CIO :- CIO i.e Common Input Output , these can be used as Bits or words , it is the same as we discussed before Input and Output Addressing .
Addressing Format :- CIO 0.0 to CIO 6143
Note :- The amount of DM , W , H and CIO in a PLC depends upon the PLC memory and vary from PLC to PLC ,
you can check it in the Memory table of PLC.
Timer / Counter Instructions in Omron PLC :-
Timers are extensively used in PLC while developing the program for any application.
In Omron there are different types of timer classified according to their Timer Base value like 100ms , 10ms.
Addressing Format of Timer :- TIM X #Y
where :- X is the Timer Number and it is from 1 to 4095.
and Y is the preset value of the Timer.
Note :- In Omron PLC all the Timer are count-down , so when the timer starts the value start decrementing
from the preset value and when it reaches 0 the timer is HIGH.
Addressing Format of Timer :- CNT X #Y
where :- X is the Counter Number and it is from 1 to 4095.
and Y is the preset value of the Counter.
Very Important Important Note :- The Timer and Counter value can not be same in Omron PLC .
For example if you have used TIM 1 then you cant use CNT 1.
How to Put Input / Output and Instructions in CX-Programmer :-
CX-Programmer is the software used to program the Omron range of PLC.
We will see the shortcuts as how to put Input and Outputs in CX-Programmer.
To put a NO contact , just press "C" and then write the address whichever you want.
To Put a NC contact , just press "/" and then write the address whichever you want.
To put an Instruction , just press "I" and write the desired Instruction.
In Omron PLC there are 8 outputs in one slot and the addressing is as follows :-
CPM1A/CPM1A PLC :- 10.0 to 10.7 , 11.0 to 11.7 and so on .
CP1E/CP1H PLC :- 100.0 to 100.7 , 101.0 to 101.7 and so on.
Work Bits :- As we all know that every PLC have some internal bits to be used in program these are known as memory or work bits.
In Omron PLC these are called WORK bits and denoted by W.
Addressing Format :- w0.0 to w512.0
Note :- There are 16 bits in one words , so w0.0 to w0.15 and then w1.0 to w1.15
Also here one important point to see is that these are used as Bits but if you want to use them as WORDS that is also possible.
DATA MEMORY WORDS :
- The data memory words in PLC are used to store the integer value or float value.
In OMRON PLC these are denoted by D and addressing Format is D0 to D322767.
HOLDING REGISTER :
- In OMRON PLC the Holding registers are there , it is similar to Data Words except it retains its state
even after power failure and also we can use it as Bits or Word.
Addressing Format :- H0 to H1535 ( is using as words)
Addressing Format :- H0.0 to H1535.15
